APTS006A0X-SRZ DC-DC Power Module Review

tangsemi

·February 12, 2025

·13 min read

The APTS006A0X-SRZ DC-DC Power Module is a dependable choice for modern power management systems. This non-isolated module combines a compact design with advanced features, making it an excellent solution for powering sensitive electronics. With a wide input voltage range of 4.5V to 14V and an adjustable output voltage from 0.59V to 5.5V, the APTS006A0X-SRZ is engineered to meet diverse application requirements. Its maximum output current of 6A ensures stable and efficient performance, even in demanding conditions.

Here’s a quick overview of its key specifications:

Specification	Value
Input Voltage Range	4.5Vdc to 14Vdc
Output Voltage Range	0.59Vdc to 5.5Vdc
Maximum Output Current	6A
Operating Temperature Range	-40°C to 85°C
Size	12.2 mm x 12.2 mm x 7.25 mm
RoHS Compliance	Yes

The APTS006A0X-SRZ also features remote On/Off control, overcurrent and overtemperature protection, and Tunable Loop™ technology for enhanced dynamic response. Its EZ-SEQUENCE™ capability streamlines output voltage sequencing, making it ideal for complex systems. Whether you’re designing for IT equipment or industrial applications, this DC-DC Power Module delivers exceptional efficiency and reliability.

Key Takeaways

The APTS006A0X-SRZ DC-DC Power Module works with input voltages from 4.5V to 14V. It can adjust output voltage between 0.59V and 5.5V, making it useful for many tasks.
It provides up to 6A of current and is 93% efficient. This means it wastes less energy and stays cooler.
Tunable Loop™ technology improves how it reacts to changes. It also reduces the need for extra parts, saving space on the circuit board.
EZ-SEQUENCE™ makes it easier to manage multiple power modules. It helps systems start and stop smoothly.
Its small size and good heat control make it strong enough for tough conditions. This ensures it lasts a long time.

Key Features of the APTS006A0X-SRZ

Technical Specifications

Input and output voltage range

The APTS006A0X-SRZ offers a flexible input voltage range of 4.5V to 14V. This wide range ensures compatibility with various power sources, making it suitable for diverse applications. You can program its output voltage from 0.59V to 5.5V, allowing precise control to meet your system's requirements. This feature makes the module ideal for powering sensitive electronics that demand stable and adjustable voltage levels.

Power rating and size

This DC-DC Power Module delivers a maximum output current of 6A, providing reliable performance even under demanding conditions. Its compact size, measuring just 12.2 mm x 12.2 mm x 7.25 mm, ensures it fits seamlessly into space-constrained designs. The small footprint makes it an excellent choice for modular systems and applications where board space is at a premium.

Efficiency and operating temperature range

The APTS006A0X-SRZ achieves an impressive efficiency of up to 93%. This high efficiency minimizes energy loss, reducing heat generation and improving overall system performance. The module operates effectively across a wide temperature range of -40°C to 85°C. This capability ensures reliable performance in both extreme cold and high-temperature environments, making it suitable for industrial and commercial applications.

Unique Selling Points

Tunable Loop™ technology

The Tunable Loop™ technology sets this non-isolated module apart. It allows you to optimize the dynamic response of the converter, reducing the need for external capacitance. This feature not only saves PCB space but also lowers costs, making your design more efficient and economical.

EZ-SEQUENCE™ capability

The EZ-SEQUENCE™ capability simplifies the coordination of multiple power modules. It enables flexible output voltage sequencing, ensuring a smooth startup and shutdown process for complex systems. This feature is particularly valuable in applications like data centers and telecommunications, where precise power management is critical.

Compact design and RoHS compliance

The APTS006A0X-SRZ combines a compact design with environmental responsibility. Its small size ensures easy integration into your circuit designs, while its RoHS compliance guarantees adherence to safety and sustainability standards. You can rely on this module to deliver high performance without compromising environmental considerations.

Performance and Efficiency

Efficiency Metrics

Efficiency under varying loads

The APTS006A0X-SRZ DC-DC Power Module delivers exceptional efficiency, even under different load conditions. You can rely on its consistent performance, which minimizes energy loss and optimizes power usage. Here are some key efficiency metrics for this non-isolated module:

Efficiency reaches up to 93%, ensuring minimal energy waste.
Maintains high efficiency across a wide range of input and output voltages.
Performs reliably under both light and heavy load conditions.

This level of efficiency makes the APTS006A0X-SRZ an excellent choice for applications where energy savings and stable performance are critical.

Energy savings in real-world applications

When you use the APTS006A0X-SRZ in real-world scenarios, you’ll notice significant energy savings. Its high efficiency reduces heat generation, which lowers cooling requirements. This feature not only saves energy but also extends the lifespan of your system. Whether you’re powering IT equipment, telecommunications systems, or industrial devices, this module ensures your energy costs remain low while maintaining reliable performance.

Thermal Management

Heat dissipation mechanisms

Effective thermal management is crucial for any power module, and the APTS006A0X-SRZ excels in this area. It incorporates advanced heat dissipation mechanisms to prevent overheating and maintain optimal performance. These features ensure the module operates reliably, even in demanding environments.

Impact of thermal performance on reliability

The thermal management features of the APTS006A0X-SRZ enhance its reliability. Here’s a breakdown of its key thermal management capabilities:

Feature	Description	Industry Standard Comparison
Thermal Shutdown	Protects the module from overheating	Commonly included in power supply modules
Over-Temperature Protection	Prevents damage by shutting down at high temperatures	Standard feature for reliability in the industry

These features ensure the module remains safe and functional, even in high-temperature conditions. By protecting against thermal stress, the APTS006A0X-SRZ maintains its performance and extends its lifespan. You can trust this module to deliver consistent results, even in challenging environments.

Applications and Compatibility

Common Use Cases

Information Technology Equipment (ITE)

The APTS006A0X-SRZ DC-DC Power Module is a reliable choice for powering IT equipment. Its high efficiency and compact design make it ideal for servers, storage devices, and networking hardware. You can use this module to ensure stable power delivery in systems where performance and reliability are critical. Its wide input voltage range and adjustable output voltage provide flexibility, allowing you to meet the specific needs of IT applications.

Telecommunications and industrial systems

This non-isolated module excels in telecommunications and industrial systems. It supports applications like base stations, routers, and industrial automation systems. You can rely on its precision and efficiency for tasks requiring accurate sensing and control. Its robust thermal management ensures consistent performance, even in challenging environments. Additionally, the module’s compact size makes it a perfect fit for space-constrained designs in these industries.

Data centers and server power supplies

Data centers and server power supplies benefit greatly from the APTS006A0X-SRZ. Its EZ-SEQUENCE™ capability simplifies the coordination of multiple power modules, ensuring smooth operation in complex systems. You can use this module to reduce energy consumption and heat generation, which are critical factors in data center environments. Its high reliability and efficiency make it a valuable asset for maintaining uptime and reducing operational costs.

System Integration

Compatibility with modular designs

The APTS006A0X-SRZ integrates seamlessly into modular designs. Its small footprint and surface-mount design allow you to incorporate it into compact systems without sacrificing performance. Whether you’re working on robotics, automotive systems, or consumer electronics, this module’s flexibility ensures it meets your design requirements. Its Tunable Loop™ technology further enhances integration by reducing the need for external components.

Integration with existing power systems

You can easily integrate the APTS006A0X-SRZ into existing power systems. Its wide input voltage range and adjustable output voltage ensure compatibility with various setups. The module’s advanced features, such as overcurrent and overtemperature protection, enhance the safety and reliability of your power solutions. Whether you’re upgrading an existing system or building a new one, this DC-DC Power Module simplifies the process while delivering exceptional performance.

Reliability and Durability

Build Quality

Materials and construction

The APTS006A0X-SRZ DC-DC Power Module is built with high-quality materials to ensure durability and performance. Its robust construction uses advanced components that resist wear and tear over time. You can trust its surface-mount design to provide a secure and reliable connection to your circuit board. The module’s compact size does not compromise its structural integrity. Every element is engineered to deliver consistent performance, even in demanding applications.

Design for harsh environments

This non-isolated module is designed to perform reliably in harsh environments. Its operating temperature range of -40°C to 85°C ensures functionality in extreme conditions. Whether you are working in cold storage facilities or high-temperature industrial settings, this module adapts to the environment. Its overtemperature protection (OTP) feature adds an extra layer of safety, preventing damage during thermal stress. You can confidently use it in rugged applications without worrying about performance degradation.

Longevity and Testing

Expected lifespan and reliability

The APTS006A0X-SRZ is engineered for long-term reliability. Its high efficiency reduces heat generation, which extends the lifespan of the components. You can expect consistent performance over years of operation. The module’s design minimizes energy loss, ensuring that it remains dependable even under continuous use. This longevity makes it a cost-effective solution for your power management needs.

Compliance with industry standards

This DC-DC Power Module complies with strict industry standards, including RoHS requirements. Its adherence to these standards ensures safety, environmental responsibility, and compatibility with modern systems. Rigorous testing during production guarantees that each module meets quality benchmarks. You can rely on its proven performance in a wide range of applications, from IT equipment to industrial systems.

Tip: When selecting a power module, always check for compliance with industry standards. It ensures reliability and safety in your designs.

Value and Cost Analysis

Price vs. Performance

Cost justification based on features

The APTS006A0X-SRZ offers a compelling balance between cost and functionality. Its advanced features, such as Tunable Loop™ technology and EZ-SEQUENCE™ capability, enhance performance while reducing the need for additional components. These features save you money on external capacitance and simplify system design. The module’s high efficiency of up to 93% also minimizes energy loss, lowering operational costs over time. Its robust protection mechanisms, including overcurrent and thermal shutdown, ensure reliable operation, reducing the risk of costly system failures. When you consider its compact size and wide application range, the APTS006A0X-SRZ provides excellent value for its price.

Suitability for budget-conscious buyers

If you are working within a tight budget, the APTS006A0X-SRZ is an excellent choice. Its small footprint and surface-mount design reduce manufacturing costs by saving PCB space. The module’s ability to operate across a wide input voltage range (4.5V to 14V) and deliver adjustable output voltages (0.6V to 5.5V) makes it versatile, eliminating the need for multiple power modules in your design. This versatility translates to cost savings, especially in large-scale applications like data centers or industrial systems. Its durability and long lifespan further enhance its cost-effectiveness, making it a smart investment for budget-conscious projects.

Market Comparison

Comparison with similar non-isolated DC-DC power modules

The APTS006A0X-SRZ stands out when compared to other non-isolated DC-DC power modules. Here’s a quick comparison of its key features:

Feature	APTS006A0X-SRZ Value
Integrated Power Switch	Yes
Overcurrent Protection	Yes
Thermal Shutdown	Yes
Input Voltage Range	4.5V to 14V
Output Voltage Range	0.6V to 5.5V
Maximum Output Current	6A
Efficiency	Up to 93%
Operating Temperature Range	-40°C to +85°C
Size	12.2 mm x 12.2 mm x 7.24 mm
Applications	Industrial, Robotics, Automotive, Consumer Electronics

This module’s combination of high efficiency, compact design, and advanced features makes it a leader in its category.

Advantages and disadvantages relative to competitors

The APTS006A0X-SRZ offers several advantages over its competitors. Its integrated power switch ensures reliable operation, while overcurrent protection and thermal shutdown enhance safety. The compact design makes it suitable for space-constrained applications, and its high reliability ensures consistent performance across various environments. Here’s a summary of its key advantages:

Feature	Description
Integrated Power Switch	Provides reliable power switching and control.
Overcurrent Protection	Ensures safe operation by detecting and responding to overcurrent conditions.
Thermal Shutdown	Protects the module from overheating, preventing damage or malfunction.
Compact Design	Notable for its small size, making it suitable for various applications.
High Reliability	Ensures consistent performance across different environments.

These features make the APTS006A0X-SRZ a superior choice for those seeking a reliable and efficient power module.

The APTS006A0X-SRZ DC-DC Power Module delivers exceptional performance and reliability, making it a standout choice for power management systems. Its advanced features, such as Tunable Loop™ technology and flexible output voltage sequencing, ensure precise control and efficiency. The module also includes robust safety mechanisms like overcurrent protection and thermal shutdown, enhancing its dependability.

Feature	Description
Tunable Loop	Optimizes dynamic output voltage response.
Flexible output voltage sequencing	Allows for customized sequencing of output voltages.
Remote sense	Enhances voltage accuracy by compensating for voltage drops.

This module excels in applications requiring compact, efficient, and reliable power solutions. It is ideal for industrial automation, robotics, automotive systems, and consumer electronics.

Application	Description
Industrial Automation	Requires precision sensing and control.
Robotics	Essential for compact power solutions.
Automotive Systems	High reliability and compact design are critical.
Consumer Electronics	Low-power, high-efficiency power supplies are needed.

With its compact design, high efficiency, and advanced features, the APTS006A0X-SRZ offers outstanding value. Whether you need a solution for IT equipment, industrial systems, or data centers, this module provides the reliability and performance you can trust.

FAQ

What is the primary purpose of the APTS006A0X-SRZ module?

The APTS006A0X-SRZ provides efficient power conversion for sensitive electronics. It ensures stable voltage output while minimizing energy loss. You can use it in applications like IT equipment, telecommunications, and industrial systems.

How does Tunable Loop™ technology benefit your design?

Tunable Loop™ technology optimizes the module's dynamic response. It reduces the need for external capacitors, saving PCB space and costs. This feature also improves system performance by ensuring faster and more stable voltage adjustments.

Can the APTS006A0X-SRZ handle extreme temperatures?

Yes, it operates reliably between -40°C and 85°C. This wide range makes it suitable for harsh environments, including industrial and outdoor applications. Its overtemperature protection ensures safety during thermal stress.

Is the APTS006A0X-SRZ easy to integrate into existing systems?

Absolutely! Its compact size and surface-mount design simplify integration. The adjustable output voltage and wide input range ensure compatibility with various setups. You can easily incorporate it into modular or existing power systems.

Why is the APTS006A0X-SRZ a cost-effective choice?

Its high efficiency reduces energy waste, lowering operational costs. Features like EZ-SEQUENCE™ and Tunable Loop™ minimize the need for additional components. These savings, combined with its durability, make it a smart investment for budget-conscious projects.
